Holz-her "Triathlon 1487" Edgebander
Preview
Holz-Her Triathlon Edgebander Auction - Erie, CO
Erie, CO
Starts In remaining
Holz-her "Triathlon 1487" Edgebander ( Preview #73224890 )
A High end cabinet maker in the greater Denver, CO area is auctioning a Holz-her "Triathlon 1487" Edgebander no longer required for continuing operations. Please call me directly with any questions.
-
Pick Up Location
405 Young Ct. Erie, CO 80516
-
Make
Holz-Her
-
Model
"Triathlon 1487"
-
Serial Number
319/0-507 5003806
-
Year
2005
-
Phase
3 PHASE
-
Voltage
230 VOLT
-
Buyer Inspection Period
July 17th - August 5th, 2025 By appointment only
-
Load Out Period
August 5th, August 12th, 2025 By appointment only
-
Estimated Dimensions
315"L x 60" W x 90" H
-
Estimated Weight
9,000 Pounds
-
Seller Comment
A Rigger is Required for load out. See homepage for details.
-
Load Fee
-
Lot Notes
-
page views
19
Holz-her "Triathlon 1487" Edgebander
SEE VIDEO OF MACHINE
3 mm PVC cap., 2-3/8" max. panel thickness and 7" min. panel length.
PREMILLING station w/Servo-Motor positioning, both JUMP controlled w/45 mm (1-3/4") milling height, 2-motors @ 2 KW (2.6 HP) - 9,000 RPM. (1961)
Granular glue hopper system with applicator nozzle & "quick melt" feature
Automatic magazine for coil, strip & solid edgebanding with motorized axis, model "1901.3" (miniscule 3° approach angle for lumber banding) w/TRACTOR-BELT feed system.
Pressure section with (3) large dia. rollers, each w/motorized plunge & pressure control, powered 1st roller with electronic speed control synchronized with chain feed speed.
"1916.1" Double motor (1 HP - 12,000 RPM ea.) end trim units with "Uni-Point" swivel system, "quick change" from flush to 0° - 15° bevel from operator panel; "1962M" Top & bottom flush trim unit (2.6 HP - 200 Cy HF motors), w/motorized 5-axis adjustment from control panel, & SIKO digital readouts.
"1906" Top & bottom fine trim unit w/motorized fine trim (1.5 HP - 200 Cy HF motors), bevels 0° - 45°, SIKO digital readouts.
"1983"Corner rounding unit for top & bottom of leading & trailing corner when edgebanding all four sides (1 motor, 0.6 HP - 200 Cy ea.), model "1983", with SIKO digital readouts, w/motorized in/out control from PLC.
"1927" Scraper Unit for finishing 3 mm PVC for radius range from 2 - 5 mm, vertical & horizontal tracing wheels, pneumatic in-and-out of knives, and SIKO readouts for easy setup.
"1851" Jump buffing unit for cleaning & polishing of panel (two 0.25 HP - 3,600 RPM motors), tilts 0° - 5°
Variable feed speed from 8 - 24 MPM (26 - 67 FPM), panel overhang beyond chain 35 mm (1.38"); features automatic track pad lubrication.
Manuals
The listed specifications & information were taken from the manufacturer’s published information, internet research, or seller’s description.
The specifications & information are assumed to be correct; however, in no way, guaranteed. Bidders are encouraged to inspect the machine, call with questions, or contact the manufacturer for more information.
